Boxchip S700A VHF/UHF + 1 Year PTT4U Service

$59 / year and one-time $799 for the Software/Radio(s) in this package

The S700A is a hybrid android radio that allows 100% coverage: via 3G/4G/LTE/WiFi/VHF or UHF FM analog and DMR Tier II. You will always be connected.

Read the FAQ
Become a PTT4U Official reseller

Choose RF Band

Category:

Description

PTT4U is a state-of-the-art network radio service. It uses the RealPTT network and can be used with any RealPTT compliant radio.

Relying on the GSM signal, our radios will be able to talk to each other without any range restriction. Each radio works with a SIM card (not included) and uses GSM/3G/4G and some models even work with WiFi signal. This means you don’t need to spend a fortune on expensive radio infra-structures, repeaters, antennas or leasing sites. All the network infra-structure is provided by the GSM carrier.

Read our FAQ section for detailed information.

Private and group calls are available. Your team members can be in different countries and still within reach. Each user can check each other’s location (based on their profile), send messages and SOS alerts.

A complete desktop Dispatch Center is also available.

All you need to do, is to purchase our network radios, depending on your needs, insert your preferred carrier SIM card on the radios (a monthly data plan of 500MB will be enough) and subscribe the yearly PTT4U service. You will need one yearly subscription for each radio. And that’s it! No more headaches.



Frequency Band UHF1: 400-470MHz or VHF: 136-174MHz
Channel 32 or customize
Channel Spacing 12.5KHz/25KHz
Working voltage 3.7V DC
Frequency stability ±1.5 ppm
Antenna impedance 50Ω,Analog 0.3μV (12dB SINAD)
Sensitivity 0.4μV (20dB SINAD)DMR 0.3μV /BER5%
Adjacent Channel Selectivity 60dB@12.5KHz
Intermodulation rejection 70dB@25KHz
Spurious response rejection 75dB@12.5/25KHz
Blocking 90dB
FM hum & noise -40dB@12.5kHz,-45dB@25kHz
Distortion at rated audio ≤5%
Frequency response mask +1 ~ -3 dB
Conducted spurious emissions < -57 dBm
Transmit power 0.5W/2W(33dBm)
FM modulation 11K0F3E@12.5KHz;16K0F3E@25KHz
4FSK Digital modulation 12.5KHz only data:7K60FXD,12.5kHz data and voice:7K60FXW
Conducted/radiated emissions -36dBm<1GHz,-30dBm>1GHz
Modulation limiting ±2.5KHz@12.5KHz,‘±5.0KHz@25KHz
FM hum & noise -40dB@12.5KHz,-45dB@25KHz
Channel power 60dB@12.5KHz,70dB@25KHz
Audio frequency response +1 ~ -3 dB
Distortion at rated audio ≤3 %
Vocoder type AMBE++
ETSI DMR ETSI-TS102 361-1,- 2,-3(*)
DMR Mode ETSI DMR Tier II
Waterproof IP67,Dustproof,Shockproof



PoC Main Parameters
Processor Octa core 1.5GHz
Android Android6.0+
LCD touch Gorilla III
Lcd touch feature Web touch/golve touch
LCD Size 4.0inches,Solar visibility
Camera 8MP+ 5MP camera;
Flash light Highlight flash LED
Dual-SIM Supported
GSM/GPRS/EDGE 850/900/1800/1900MHz
GSM B2 B3 B5 B8
WCDMA B1 B2 B5 B8
TD-SCDMA B34 B39
FDD-LTE B1 B2 B3 B4 B5 B7 B8 B28A B28B
TDD-LTE B38 B39 B40 B41
VOLTE Support
Bluetooth Bluetooth 4.1
NFC Support or Optional
Battery capacity 4500mAh
Wi-Fi (WLAN) 2.4G/5.8G, IEEE 802.11b/g/n
GPS navigation GPS/AGPS/GLONASS

Learn how to program the S700A DMR frequencies.
